Frameset
Frame
Invenio Adventure A (Hydro Series aluminium), size M
Fork
4ZA Oryx Disc 12TA
The Ridley Invenio Alu is an aluminium gravel and all-road platform aimed at riders who need one bike to cover mixed-surface riding, commuting, and light adventure use. Rather than chasing the current trend toward aggressive race-gravel geometry, this model is built around a more stable, comfort-oriented layout, a 4ZA Oryx Disc fork, disc brakes, and clearance for 700c tires up to 42 mm. Ridley also positions it as a practical bike, with fender compatibility and numerous mounting points that make it more relevant for utility riding and bikepacking than for stripped-down competitive gravel use.
What makes this model notable is that it appears to be less a ground-up new platform than a reworked presentation of Ridley’s existing alloy gravel architecture, tied to the Tomorrowland x Ridley Invenio collaboration. The published geometry strongly suggests it shares its underlying frame platform with the earlier Kanzo A. That places the Invenio Alu in a familiar part of the market: an accessible, versatile alloy gravel bike that prioritizes durability, predictable handling, and day-to-day usefulness over low weight or cutting-edge race intent.

| Stack | 584mm |
| Reach | 386mm |
| Top tube | 565mm |
| Headtube length | 158mm |
| Standover height | 835mm |
| Seat tube length | 540mm |
The geometry points clearly toward stability and all-day comfort rather than quick, race-oriented handling. Across the size range, the head tube angle stays relatively relaxed at 70.0 to 71.5 degrees, while the chainstay length is a consistent 430 mm. Combined with wheelbases from 1016 mm in XXS to 1066 mm in XL, that should give the bike a planted feel on rough roads and gravel, with calmer steering and good straight-line composure. BB drop ranges from 70 to 74 mm, which also supports a more settled ride feel by keeping the rider reasonably low in the bike.
Fit numbers are moderate and conservative. Reach runs from 374 mm in XXS to 399 mm in XL, while stack spans 528 to 636 mm, indicating a fairly upright riding position compared with more aggressive gravel race bikes. The effective top tube lengths, from 515 to 600 mm, and the steeper seat tube angles on the smaller sizes help keep rider position sensible across the range. Overall, the numbers suggest a bike that should feel approachable and comfortable for long mixed-surface rides, commuting, and loaded use, without especially sharp or responsive front-end behavior.
Frameset
Frame
Invenio Adventure A (Hydro Series aluminium), size M
Fork
4ZA Oryx Disc 12TA
Groupset
Shift levers
Shimano GRX400, 2x10-speed
Front derailleur
Shimano GRX 400, 2x10-speed
Rear derailleur
Shimano GRX 400, 10-speed, max 36T
Cassette
Shimano HG50, 10-speed, 11-36T
Chain
Shimano 10-speed (GRX-level)
Crankset
Shimano GRX 600, 172.5mm, 46/30T (2x10)
Bottom bracket
Shimano GRX / Hollowtech II (BSA/threaded type not specified)
Front brake
Shimano GRX400 hydraulic disc brake
Rear brake
Shimano GRX400 hydraulic disc brake
Front rotor
Shimano hydraulic disc rotor (size not specified)
Rear rotor
Shimano hydraulic disc rotor (size not specified)
Wheelset
Front wheel
4ZA Norte G F 24TLR - 3BF db - TML D1061
Rear wheel
4ZA Norte G R 24TLR - 3BFdb GEN3 SHI - TML D1061
Front tire
Vittoria Terreno T30, 700x40c, rigid, full black (OEM)
Rear tire
Vittoria Terreno T30, 700x40c, rigid, full black (OEM)
Cockpit
Stem
Forza Stratos, 100 mm, Black Glossy
Handlebars
4ZA Stratos Gravel, 420/480
Saddle
Selle Italia SLR Boost, Special TML Edition, manganese rails, black
Seatpost
Forza Stratos, zero offset, 350mm, 27.2mm, Black Glossy
The available build information is limited to a single Shimano GRX400 2x10-speed specification, so this generation appears to be offered in a straightforward, mid-level configuration rather than across a broad range of trims. GRX400 is a sensible match for the bike’s intended use: it delivers gravel-specific ergonomics and wide enough gearing for mixed terrain, while keeping cost and maintenance more manageable than higher-end 11- or 12-speed groups.
Given the frame’s aluminium construction, 4ZA Oryx Disc fork, disc-brake layout, 42 mm tire clearance, and utility-focused mounting provisions, the spec direction is clearly about practicality rather than premium weight savings. With only one known build, the appeal is less about choosing between component tiers and more about getting a complete, ready-to-use adventure and commuting platform with a proven drivetrain standard.

Shimano GRX400 2x10sp
Price TBD
